AEMC PC Scope Module Model MTX 1052B-PC

Click image to enlarge

(Part #2150.10)

Mfg: AEMC®

Additional Model Number: MTX 1052B-PC

Price Each: $0.00

Quantity:

******Discontinued******
The MTX 1052B-PC is a two-channel oscilloscope with 150MHz bandwidth and a vertical sensitivity from 250uV to 100V/div with 10 bit resolution. USB or Ethernet communication enables programing the instrument remotely with the supplied software. The instrument is compact, lightweight and stackable; and is rated 300V CAT III.

Features

Oscilloscope with FFT, harmonic analyzer and recorder
Sampling rate 200MS/s in one-shot mode and 100GS/s in ETS mode
Detects 10ns transients
10-bit A/D converter
Vertical sensitivities of 250μV-100V/div (300V CAT II)
Advanced trigger modes and SPO (Smart Persistence Oscilloscope) analysis

Technical Resources

Accessories

Please add a quantity to the following accessories before clicking the "Add to Quote" or "Add to Cart" to add items to your order/quote.

AEMC Adapter (Part# 2118.46)
Part #: 2118.46
$46.25

Quantity:

AEMC Adapter (Cat# 2118.46) - Banana (Female) - BNC (Male) (XM-BB) for use with AmpFlex Sensors, Models K100/K110 and SLII Data Loggers(600V CAT III)
